Ben Routley
Precision Mechatronics Lab
School of Electrical Engineering and Computer Science
The University of Newcastle
Callaghan, NSW 2308, Australia
+61 2 4921 7463
Ben(dot)Routley(at)newcastle.edu.au
Biography
Ben Routley is a research assistant with the School of Electrical Engineering and Computer Science at The University of Newcastle, with a specialization in Near-field optics. He is interested in probe based lithography and computer modelling. Currently he is completing a PhD with the School of Mathematical and Physical Sciences with a specialization in Organic Photo-voltaic devices.
Publications
2022
16.
L. R. McCourt; B. S. Routley; M. G. Ruppert; V. J. Keast; C. I. Sathish; R. Borah; R. V. Goreham; A. J. Fleming
In: ACS Applied Nano Materials, vol. 5, iss. 7, pp. 9024-9033, 2022, ISSN: 2574-0970.
@article{nokey,
title = {Single-Walled Carbon Nanotubes as One-Dimensional Scattering Surfaces for Measuring Point Spread Functions and Performance of Tip-Enhanced Raman Spectroscopy Probes},
author = {L. R. McCourt and B. S. Routley and M. G. Ruppert and V. J. Keast and C. I. Sathish and R. Borah and R. V. Goreham and A. J. Fleming},
url = {https://www.precisionmechatronicslab.com/wp-content/uploads/2023/02/J22i.pdf},
doi = {10.1021/acsanm.2c01274},
issn = {2574-0970},
year = {2022},
date = {2022-06-21},
urldate = {2022-06-21},
journal = {ACS Applied Nano Materials},
volume = {5},
issue = {7},
pages = {9024-9033},
abstract = {This Article describes a method for the characterization of the imaging performance of tip-enhanced Raman spectroscopy probes. The proposed method identifies single-walled carbon nanotubes that are suitable as one-dimensional Raman scattering objects by using atomic force microscope maps and exciting the radial breathing mode using 785 nm illumination. High-resolution cross sections of the nanotubes are collected, and the point spread functions are calculated along with the optical contrast and spot diameter. The method is used to characterize several probes, which results in a set of imaging recommendations and a summary of limitations for each probe. Elemental analysis and boundary element simulations are used to explain the formation of multiple peaks in the point spread functions as a consequence of random grain formation on the probe surface.},
keywords = {},
pubstate = {published},
tppubtype = {article}
}
This Article describes a method for the characterization of the imaging performance of tip-enhanced Raman spectroscopy probes. The proposed method identifies single-walled carbon nanotubes that are suitable as one-dimensional Raman scattering objects by using atomic force microscope maps and exciting the radial breathing mode using 785 nm illumination. High-resolution cross sections of the nanotubes are collected, and the point spread functions are calculated along with the optical contrast and spot diameter. The method is used to characterize several probes, which results in a set of imaging recommendations and a summary of limitations for each probe. Elemental analysis and boundary element simulations are used to explain the formation of multiple peaks in the point spread functions as a consequence of random grain formation on the probe surface.
